NEDRPC-6412A-4U4UP
DIN-Rail Computer
Features
162W x 115D x 61H (mm)
Intel® Celeron® J6412 Processor
Dual Channel DDR4 3200MHz
4 x COM (RS232/422/485)
4 x COM (RS485)
4 x COM (RS485 with power line)
2 x GbE LAN Ports
SPEC
| Model name | NEDRPC-6412A-4U4UP | |
|---|---|---|
| System Core | CPU | Intel® Celeron® J6412 Processor 10nm, 4 cores, 4 threads, up to 2.60GHz TDP 10W |
| Memory | 1 x DDR4 SO-DIMM sockets, Max, Capacity 32 GB Support Dual Channel DDR4 3200 MHz memory modules |
|
| Video | Integrated Graphics Processor Intel® UHD Graphics for 10th Gen Intel® Processors |
|
| Thermal Design | Fanless | |
| Panel I/O | Video Port | Integrated Graphics Processor Intel® UHD Graphics for 10th Gen Intel® Processors 2 x HDMI 2.0 port, supporting a maximum resolution of 4096x2160 @60Hz |
| Ethemet | 2 x RJ45 LAN Ports | |
| USB | 4 x USB 3.2 Gen 1 | |
| Serial Port | 4 x RS485 4 x power line on RS485 |
|
| Audio | Realtek® Audio Codec 1 x Headphone Jack |
|
| Side I/O | Serial Port | 2 x RS232 2 x RS232/422/485 |
| Storage | Storage Interface | 1 x 2280 M.2 M-Key (PCle x2, SATA 6Gb/s) |
| Internal Expansion Bus | Full-size mini PCle | |
| Expansion Connector | 1x GPIO (8 bits) & SMBus header 2 x USB 2.0 headers |
|
| Power Supply | DC Input | 2-Pin terminal block |
| Power Input Range | +9V~ 36VDC | |
| LED Indicator | Power on & HDD in power button | |
| Net Weight | 1.1 KG | |
| Mounting | DIN rail Wall mount (Optional) |
|
| Operating Temperature | Operating temperature : -20°C to 70°C Operating humidity : 0-90% (non-condensing) Non-operating temperature : -40°C to 85°C Non-Operating humidity : 0-95% (non-condensing) Use wide temperature range memory and storage |
|
| Vibration During Operation | Operation : IEC 60068-2-6, 2 G, Sine, 10~500Hz, 1Oct/min, 1hr/ Per Axis Non-Operation : IEC 60068-2-64, 3Grms, random, 5~500Hz, 1hr/Per Axis, with SSD/M.2 2280 |
|
| Shock During Operaiton | Operation : IEC 60068-2-27, 50 G, half sine, 11 ms duration, with SSD |
|
| Operating System | Windows 10 (x64), Linux, Ubuntu | |
| Built-in Software | ||
| Accessories | Terminal Blocks 1*2P x 1 Terminal Blocks 2*3P x 4 AC-DC Power Adapter 60W x 1 |
For More product information, please download our Datasheet.
Description
NEDPRC Series is designed with the latest Elkhart Lake processor which can connect with a range of devices through different built-in IO ports. Customers can add Wi-Fi or Bluetooth modules, storage, AI accelerators, etc. Our single board computer can operate at a wide temperature from -20°C ~ +65°C. With high reliability and long lifetime support, it’s the best fit for various industry 4.0 applications. Such as data collection, industrial controllers, intelligent gateway systems, PC-based testing equipment, and machine failure prediction.
Our “IoT Gateway” integrated OT protocols with IT & Cloud Platform communications. With ready-to-use & customizable software, it realized data collection, device connectivity, and remote control that can benefit IoT developers and system integrators with flexibility, compatibility, and cost-effectiveness.
