ARM
Single Board Computer
Features
TI Sitara AM335X @600MHz, 800Mhz or 1GHz
CANbus, I2C x 3, Stereo Audio, GPIO
4GB eMMC Flash
18-bit and 24-bit LVDS LCD
10/100Mbps Ethernet x 2
512MB DDR3
SDHC/SDIO
COM x 3, USB 2.0 x 2
Typical 2.5W
SPEC
| Model name | ARM | ||
|---|---|---|---|
| Technical Information | Processor | TI Sitara AM335X | |
| ARM Cortex-A8 at 600MHz, 800MHz or 1GHz | |||
| Memory | Onboard 4GB eMMC Flash (eMMC 5.x) | ||
| Onboard 512MB DDR3L (400Mhz x 2)記憶體 | |||
| Onboard AT24C32 EEPROM | |||
| Networking | 2 x 10/100 Mbps RJ45 Ethernet Jack | ||
| Display | Single channel LVDS 18-bit and 24-bit color depth interfaces (two connectors) | ||
| Expansion | 1 x SDHC/SDIO, 1 x USB 2.0 Host Type A Connector | ||
| USB | 1 x USB 2.0 Host Type A connector, 1 x USB 2.0 OTG mini-USB connector | ||
| Additional Interface | 3 x RS232s (transceiver onboard, and one can be configured as RS422/RS485) | ||
| 2 x SPIs header | |||
| 2 x I2C header | |||
| Audio with Microphone input and Headphones output header | |||
| 1 x CAN Bus Header (Transceiver onboard) | |||
| RTC (Seiko S35390-A) backup battery onboard | |||
| 1 x Buzzer | |||
| 12 x GPIOs header | |||
| 1 x 4-wire touch connector | |||
| Other Features | Invisible reset jumper | ||
| external watchdog reset (reset from the power source) | |||
| LCD LED backlight driver onboard | |||
| SW Support | Linux 4.9.41 (Based on TI Processor SDK 04.01.00.06) or Linux 4.4.12 (Based on TI Processor SDK 03.00.00.04) or Linux 4.1.10 (Based on TI Processor SDK 02.00.01.07) or Linux 3.14.43 (Based on TI Processor SDK 01.00.00.03) or Linux 3.12.y (Based on TI AMSDK 7.0.1) or Linux 3.2 (Based on TI AMSDK 6.0.0) | ||
| Support Ubuntu 14.04/16.04 LTS or Debian 9 | |||
| Support Yocto Project | |||
| Power Consumption | 2.5 Watts Typical | ||
| Environment | Thermal | Normal Temperature: 0oC ~ 60oC Industrial Temperature: -40o ~85oC | |
| Humidity | 10% ~ 90% relative humidity, non-condensed | ||
| Power Supply | Single 5V | Terminal block connector and miswiring protection | |
| Form Factor | 3.5-inch | 102 mm (L) x 145 mm (W) | |
For More product information
Description
SBC-SMART-BEE Single Board Computer is based on TI Sitara AM335X ARM Cortex-A8 technology (600MHz,800Mhz or 1GHz).
This product is aiming to replace current ARM9, ARM11 and part of the Cortex-A8 markets in higher resolution displays, faster performance and multiple, flexible integrated connectivity options — all while keep the power level low and price competitive.
The SBC consists of a SMARC module and a application-oriented carrier board. Users can easily upgrade or expand their system by taking advantages of this architecture.
Possible Applications
● HVAC Building and Control Systems
● Fire Alarms
● Smart Grid and Smart Metering
● Home Gateway
● HMI/ In-Home Display
● Smart Toll Systems
● Connected Vending Machines
● Fiscal Printer/ Weighing Scales/ Currency Counter
● Education
● The Internet of Things (IOT)
● Access Control
